Hardness testing in the laboratory: reliable and efficient quality assurance

When hardness is tested in laboratories, such as quality assurance laboratories within production facilities, independent contract laboratories or research laboratories, which use hardness testing for research and development purposes (e.g. in research institutes), then good options for documenting hardness testing tasks within the scope of a test report are important. In addition, simply and highly automated administration of the measurement data, as well as its transfer to and back-up in an in-house QM system, are key criteria in the selection of a hardness testing machine and essential for a reliable and efficient quality assurance process.

Test laboratories, Research & Development

Our References

voestalpine Stahl GmbH - DuraVision

Automated hardness testing with structured data import and export - with DuraVision

testing up to 72 samples fully automatically with a range of methods
different sample heights
connection to the customer’s own database

Filename

Type

Filesize
Referenz downloaden pdf 201 KB 

"The device technology is very advanced compared to the competition. Plus, the product is developed in-house by EMCO-TEST. This was very important to us because it means we have a clearly defined point of contact."

Mechanical-Physical Test Laboratory Manager

Bosch - DuraScan

M + S Hydraulic - DuraVision

Palfinger AG - DuraVision & DuraScan

Rockmore - DuraScan

Wippermann jr. GmbH - DuraScan & areaMaster

Hardness testing on anodised coatings and glass - with DuraScan

“

I also find the price-performance relationship great. Even after the purchase, we’re constantly supplied with free updates.

Employee in Test and Measurement

“

The fast and reliable functioning of the DuraScan 70 persuaded us on our first demonstration.

Matthias Richter, Engineering

“

We are confident that EMCO-TEST products meet our quality requirements.

Bernhard Eicher, Head of the Palfinger CCF Analysis Center

“

If we had to describe our hardness tester in just three words, we would call it fast, easy and convenient.

Jan Ivanov, Head of Physics Laboratory

Test laboratories, Research & Development

Application Examples

Micro hardness testing of welded joints - with DuraScan Automatic (70,80)

Weld sample testing according to DIN EN ISO 9050 can be conducted simply, in a time-saving manner, with the fully automatic DuraScan micro hardness tester.

Simple test sequence creation
Positioning with a panorama function
Time-saving template mode

First, the test type (sequential) and test method (HV0,1-HV5) are selected in the ecos Workflow operating software. The test points can be arranged conveniently in a grid pattern in the test point editor. The test sequences can be adapted automatically to the contours of the workpiece using the line and polygon tool. Another integrated tool makes it possible to adhere to the standard-compliant spacings. The position of the test sequences can then be defined simply and transparently in the real-time image. Larger specimens are likewise completely mapped using the panorama function.

A template for every measured and archived specimen is also created automatically. This template can then be used with the next weld seam and positioned on the workpiece using the rotation axis. In this way, even complicated test tasks can be carried out quickly in a matter of clicks.

Weld sample mapping - with DuraScan Automatic (50, 70, 80) and areaMASTER software module

The fully automatic DuraScan micro hardness tester in combination with the areaMASTER software module is suitable for determining the hardness distribution of a weld sample and displaying it clearly.

Contour scan with edgeAssistant
Automatic test point distribution
Depiction of the hardness distribution

After selecting the test type (mapping) and test method (e.g. HV1) in the ecos Workflow operating software, the next step is for the contour of the specimen to be traced automatically with the help of edgeAssistant. Subsequently, all that remains to be done is to enter the required test point spacings. The software automatically distributes these across the specimen and the measurement can be started.

Once the measurement has been completed, a hardness profile of the weld sample (similar to a finite element analysis) is provided, which clearly displays the hardness distribution in a colour "hardness map" (in 2D or 3D).

More about the AareaMASTER

Test data management - with DuraJet G5

In order to save all available test data simply and clearly, the DuraJet G5 Rockwell tester can archive the data in a structured manner.

Standard test data management
Grouped test data management, e.g. for batches, departments, etc.

The preferred type of test data management is selected prior to testing. In the standard test data management system, all results are stored in a collective list.

If test data needs to be associated with individual users or user groups, specific components, batches or departments, then the grouped data management function should be used. All the determined test results are compiled in separate lists, allowing them to be clearly represented, exported or saved as a report. The groups created can be reloaded at any time and augmented with additional test results.

Multiple testing of embedded specimens - with DuraScan Automatic and ecos Workflow software module

Up to twelve embedded specimens, each comprising several test sequences, can be measured fully automatically with the DuraScan micro hardness tester in combination with the ecos Workflow multi-specimen software module.

Automatic testing of up to twelve embedded specimens
Test points positioned quickly and easily with the help of the overview camera
High travel through asymmetric arrangement

Up to twelve embedded specimens can be inserted and processed in parallel using the ecos Workflow multi-specimen software module. The test data and test sequence can be specified for each individual specimen, and the measurement can then be executed fully automatically. Positioning of test points and test sequences is simplified by the overview camera.

ecos Workflow

Automated hardness testing - with DuraVision Semi-Automatic or DuraJet G5

It is possible to integrate a hardness tester into a production line via a hardware interface. This enables external control of the machine.

External machine control
Option to connect foot switch

Both the DuraVision Semi-Automatic universal hardness tester and the DuraJet G5 Rockwell tester are equipped with an additional interface. This additional interface allows 100% tests to be conducted without having to remove test specimens from the production process.

Another option is to connect the available foot pedal to the interface, in order to use this for performing the clamping movement to fix a workpiece. The significantly simplifies handling in tests on large, unwieldy components.
